Xianju Qingfang Automobile Parts Co., Ltd.
double ear hose clamp
Product name : double ear hose clamp
Model No. : qf0047
Price : 0.1usd/pcs
Products Category: > hose clamp > double ear hose clamp
pecifications
Galvanized Double Ears Hose Clamp
1.Band width:6-10mm
2.Diameter: 46mm.etc
3.Thickness: 0.7-1.6mm
4.ISO,SQC
Galvanized Double Ears Hose Clamp
Galvanized Steel Double Ear Hose Clamp
1. Robust design for good, permanent sealing
2. Ideal for air and liquid lines
3. Fast, simple, secure installation
4. 2-Ear design gives increased clamping range
5. De-burred edges prevents damage to clamped parts
6. Deformation of ears provides visual indication that clamp is closed
Use Recommend:
1. Recommends pneumatic pincers with electronic gauging, to ensure repeatable assembly and uniform closure, particularly for mass production applications
2. Ear Clips are available in application tools
| Material | No. | Size range (mm) | Bandwidth*Thickness(mm) |
| All galvanized steel | Tello-01 | 3--5 | 6×0.7 |
| Tello-02 | 5--7 | 6×0.7 | |
| Tello-03 | 7--9 | 7×0.7 | |
| Tello-04 | 9--11 | 7×0.9 | |
| Tello-05 | 11--13 | 7×1.0 | |
| Tello-06 | 13--15 | 7.5×1.0 | |
| Tello-07 | 15--18 | 7.5×1.2 | |
| Tello-08 | 17--20 | 7.5×1.2 | |
| Tello-09 | 20--23 | 9×1.3 | |
| Tello-10 | 21--25 | 9×1.3 | |
| Tello-11 | 23--27 | 9×1.4 | |
| Tello-12 | 25--28 | 9×1.4 | |
| Tello-13 | 28--31 | 9.5×1.4 | |
| Tello-14 | 31--34 | 9.5×1.4 | |
| Tello-15 | 34--37 | 9.5×1.5 | |
| Tello-16 | 37--40 | 10×1.6 | |
| Tello-17 | 40--43 | 10×1.6 | |
| Tello-18 | 43--46 | 10×1.6 |
Our other main types clamps:
1)America style hose clip clamps(12mm,12.7mm,14mm)
2)stainless steel hose clip clamps with handle
3)heavy duty stainless steel hose clip clamps/strong stainless steel hose clip
4)quick/fast realsed stainless steel hose clip
5)double wire hose clip clamps
6)two bolt hose clip clamps
OEM service available
Completely made of stainless steel. It is the most powerful hose clip clamps within the product range.
Material:201
304 0Cr18Ni9 304L 00Cr19Ni10
321 0Cr18Ni9Ti 316 0Cr17Ni12Mo2
316L 00Cr17Ni14Mo2 310S 0Cr25Ni20
