12mm Bandwidth German Type Hose Clamp
Product name : 12mm Bandwidth German Type Hose Clamp
Model No. : qf0015
Price : 0.089usd/pcs
Products Category: > Germany type hose clamp > bandwidth 12mm
Material Specifications
Screw: 7 mm hex-head. Carbon steel or 400 / 200 / 300 grade stainless steel.
Band: 12mm band width. Non-perforated. Carbon steel or 400 / 200 / 300 grade stainless steel. .
Housing: Carbon steel or 400 / 200 / 300 grade stainless steel.
size and clamping range chart
SAE Sizes | dia.min.-max.(mm) | dia.min-max.(in.) | torque performance installation(in.-lbs.) | torque performance installation(nm) | torque performance ultimate(in.-lbs.) | torque performance ultimate(nm) |
| 1 | 8-12 | 5/16--15/32 | 18.0 | 2.0 | 35 | 4.0 |
| 2 | 8-16 | 5/16--5/8 | 18.0 | 2.0 | 35 | 4.0 |
| 3 | 12-20 | 15/32--25/32 | 26.0 | 3.0 | 40 | 4.5 |
| 4 | 12-22 | 15/32--7/8 | 26.0 | 3.0 | 40 | 4.5 |
| 5 | 16-27 | 5/8--1-1/16 | 26.0 | 3.0 | 40 | 4.5 |
| 6 | 20-32 | 25/32--1-1/4 | 26.0 | 3.0 | 40 | 4.5 |
| 7 | 25-40 | 1--1-1/9 | 26.0 | 3.0 | 40 | 4.5 |
| 8 | 30-45 | 1-3/16--1-3/4 | 26.0 | 3.0 | 40 | 4.5 |
| 9 | 32-50 | 1-1/4--1-31/32 | 26.0 | 3.0 | 40 | 4.5 |
| 10 | 40-60 | 1-9/16--2-3/8 | 26.0 | 3.0 | 40 | 4.5 |
| 11 | 50-70 | 1-31/32--2-3/4 | 26.0 | 3.0 | 40 | 4.5 |
| 12 | 60-80 | 2-3/8--3-1/8 | 26.0 | 3.0 | 40 | 4.5 |
| 13 | 70-90 | 2-3/4--3-1/2 | 26.0 | 3.0 | 40 | 4.5 |
| 14 | 80-100 | 3-1/8--3-15/16 | 26.0 | 3.0 | 40 | 4.5 |
| 15 | 90-110 | 3-1/2--4-5/16 | 26.0 | 3.0 | 40 | 4.5 |
| 16 | 100-120 | 3-5/16--4-23/32 | 26.0 | 3.0 | 40 | 4.5 |
| 17 | 110-130 | 4-5/16--5-1/8 | 26.0 | 3.0 | 40 | 4.5 |
| 18 | 120-140 | 4-23/32--5-1/2 | 26.0 | 3.0 | 40 | 4.5 |
| 19 | 130-150 | 5-1/8--5-29/32 | 26.0 | 3.0 | 40 | 4.5 |
| 20 | 140-160 | 5-1/2--6-5/16 | 26.0 | 3.0 | 40 | 4.5 |
